Comparison Chart

Dispense Volume by Setting Period (Months)

#	Model	¼	½	1	2	3	6	12	18	24	30	36
1	TL-EX 175cc (discontinued)	—	—	—	—	—	—	—	—	—	—	—
2	TL-EC1 60cc daily dispense	N/A	N/A	2.00 cc	N/A	0.67 cc	0.33 cc	0.17 cc	N/A	N/A	N/A	N/A
3	TL-EC2 120cc daily dispense	N/A	N/A	4.00 cc	N/A	1.33 cc	0.67 cc	0.33 cc	N/A	N/A	N/A	N/A
4	TL-EC3 240cc daily dispense	N/A	N/A	8.00 cc	N/A	2.66 cc	1.33 cc	0.67 cc	N/A	N/A	N/A	N/A
5	TL-D1 125cc daily dispense	N/A	N/A	4.20 cc	2.10 cc	1.40 cc	0.70 cc	0.35 cc	N/A	N/A	N/A	N/A
6	TL-D2 250cc daily dispense	N/A	N/A	8.30 cc	4.20 cc	2.80 cc	1.40 cc	0.70 cc	N/A	N/A	N/A	N/A
7	TL-M1 / MSB1 / M1EX1 125cc daily dispense	N/A	N/A	8.30 cc	4.20 cc	1.40 cc	0.70 cc	0.35 cc	N/A	N/A	N/A	N/A
8	TL-M2 / MSB2 / M2EX2 250cc daily dispense	N/A	N/A	16.60 cc	8.30 cc	2.80 cc	1.40 cc	0.70 cc	N/A	N/A	N/A	N/A
9	TL-M3 / MS3 500cc daily dispense	N/A	N/A	33.30 cc	16.60 cc	4.20 cc	2.80 cc	1.40 cc	0.90 cc	0.70 cc	N/A	N/A
10	TL-PLC1 60cc daily dispense (month type)	N/A	N/A	2.00 cc	1.00 cc	0.67 cc	0.33 cc	0.17 cc	N/A	N/A	N/A	N/A
11	TL-PLC2 120cc daily dispense (month type)	N/A	N/A	4.00 cc	2.00 cc	1.33 cc	0.67 cc	0.33 cc	N/A	N/A	N/A	N/A
12	TL-PLC3 240cc daily dispense (month type)	N/A	N/A	8.00 cc	4.00 cc	2.66 cc	1.33 cc	0.67 cc	N/A	N/A	N/A	N/A
13	TL-PLC4 480cc daily dispense (month type)	N/A	N/A	16.00 cc	8.00 cc	4.00 cc	2.66 cc	1.33 cc	N/A	N/A	N/A	N/A
14	TL-PLL all sizes (set mode type)	N/A	N/A	—	—	—	—	—	N/A	N/A	N/A	N/A
15	TL-OL 500cc	—	—	See dispense rate chart in User Manual

Model Range Technical Specifications

Model range	Dispense fill	Operational control	Settings system	Locations	Refillable	Bearings served	Remote maximum	Setting maximum	Temperature range	Lithium low-temp option (-40 °C)	Machine synchronized	External power
TL-S1	Grease	Spring power	Top knob*	Normal**	Yes	1	N/A	N/A	-30 °C to 121 °C	No	No	No
TL-EC1, EC2, EC3	Grease or oil	Electrochemical	Selector pin	Normal	No	1	3 ft	12 mos	-20 °C to 55 °C	No	No	No
TL-D1, D2	Grease	Electromechanical	Digital/LCD	Normal	No	1	3 ft	12 mos	-20 °C to 55 °C	No	No	No
TL-M1, M2	Grease	Electromechanical	Digital/LCD	Normal	Yes	1–8	20 ft	12 mos	-15 °C to 60 °C	Yes	Yes	Yes
TL-M3 (500cc)	Grease	Electromechanical	Digital/LCD	Normal	Yes	1–8	20 ft	24 mos	-15 °C to 60 °C	Yes	Yes	Yes
TL-MSB1, MSB2	Grease	Electromechanical	Digital/LCD	Normal	Yes	1–8	20 ft	12 mos	-20 °C to 55 °C	No	Yes	Yes
TL-MS3 (500cc)	Grease	Electromechanical	Digital/LCD	Normal	Yes	1–8	20 ft	24 mos	-15 °C to 60 °C	Yes	Yes	Yes
TL-MEX1	Grease	Electromechanical	Digital/LCD	Hazardous	Yes	1	10 ft	12 mos	-15 °C to 60 °C	No	No	No
TL-MEX2	Grease	Electromechanical	Digital/LCD	Hazardous	Yes	1	10 ft	12 mos	-15 °C to 60 °C	No	No	No
TL-EXPL1 (60cc)	Grease	Electromechanical	Digital/LCD	Hazardous	Yes	1–8	10 ft	12 mos	-15 °C to 50 °C	No	No	No
TL-EXPL2 (120cc)	Grease	Electromechanical	Digital/LCD	Hazardous	Yes	1–8	10 ft	12 mos	-15 °C to 50 °C	No	No	No
TL-EXPL3 (240cc)	Grease	Electromechanical	Digital/LCD	Hazardous	Yes	1–8	10 ft	12 mos	-15 °C to 50 °C	No	No	No
TL-EXPL4 (480cc)	Grease	Electromechanical	Digital/LCD	Hazardous	Yes	1–8	10 ft	12 mos	-15 °C to 50 °C	No	No	No
TL-PLC1, 2, 3, 4***	Grease	Electromechanical	Digital/LCD	Normal	Yes	1–8	8 ft	12 mos	-20 °C to 60 °C	No	Yes	Yes
TL-OL1, 2, 3, 4****	Grease	Electromechanical	Digital/LCD	Normal	Yes	1–8	8 ft	6 mos	-20 °C to 60 °C	No	Yes	Yes
TL-OL 500cc	Oil	Electromechanical	Digital/LCD	Normal	Yes	1–4	20 ft	24 mos	-15 °C to 60 °C	Yes	Yes	Yes
TL-EO1, EO2, EO3	Oil	Electrochemical	Selector pin	Normal	No	1	3 ft	12 mos	-20 °C to 55 °C	No	No	No
